Product features:

       Negative pressure in whole cycle
Chamber pressure is always negative in whole cycle ensures EO gas no leakage to outside during working.

       Safety EO gas puncture device
EO gas can automatically punctured by special device in the chamber, no need human intervention.

       Chamber pressure real-time monitoring function:
Any pressure abnormal in the chamber will cause the machine alarm.

       Efficient ventilation system
Automatic pulse Vacuum ventilation ensures EO gas exhaust thoroughly.

       Door interlock
The door cannot be opened while program is running.

       EO gas concentration monitor(optional)
Accuracy:0.1ppm, portable design.

       Accurate parameter control
Sterilization temperature, humidity, pressure and time data are collected by relative sensor and transferred to PLC.

       Perfect chamber temperature conducting
Chamber is made of aluminum alloy which has good thermal conductivity makes chamber temperature conducting fast and uniformity.

       Dual sterilization temperature choices
Humidity sensor in high accuracy ensures chamber humidity keep in stable level.

       Power off memory function
Once power off, the sterilization data will be saved automatically and will automatically continue the sterilization when power on.

Technical parameters:

Model	EOGC0961	EOGC0961
Chamber dimension(mm)	750x860x400	1250x860x1730
Overall dimension	950x860x1730	1450x860x1730
Chamber volume L	135	225
Net weight Kg	300	400
Input power	3.5kVA,220V,50Hz	4.5Kva,220V,50Hz

EO gas can
Net weight	100g	170g
Sterilization concentration	735mg/L	750mg/L
Automatic lifting trolley
Loading platform dimension(mm)	800X400	1300X400
Overall dimension	1150x780x1165	1650x780x1165
Sterilization concentration	735mg/L	750mg/L
Lifting range	720-1220	720-1220
Max load capacity Kg	100	150
Weight	55	70
